How to Set Up Nginx as a Reverse Proxy for Apache Superset

Abdul Wahab Junaid

3 years ago

How to Set Up Nginx as a Reverse Proxy for Apache Superset

Setting up Nginx as a reverse proxy for Apache Superset can help improve security, handle SSL termination, and provide additional features like load balancing. Here’s a step-by-step guide:

1. Install Nginx:

If Nginx is not already installed on your server, you can install it using your package manager. On Ubuntu, you can use:

Bash

sudo apt update
sudo apt install nginx

2. Install and Set Up Apache Superset:

Before configuring Nginx, make sure you have Apache Superset properly installed and configured on your server. Follow the official documentation to set up Superset: Apache Superset Installation Guide.

3. Configure Apache Superset:

Ensure Apache Superset is running and listening on a local IP address and port (e.g., 127.0.0.1:8088). You will configure Nginx to proxy requests to this address.

4. Configure Nginx:

Create a new Nginx configuration file for Apache Superset. You can create this file in the /etc/nginx/conf.d/ directory:

Bash

sudo nano /etc/nginx/conf.d/superset.conf

Add the following configuration:

Bash

server {
    listen 80;
    server_name superset.example.com; # Replace with your domain or server IP

    location / {
        proxy_pass http://127.0.0.1:8088; # Address and port of your Superset instance
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

listen 80: Listens on port 80 (HTTP).
server_name: Replace with your Superset domain or server IP.
location /: Handles requests to the Superset proxy.
proxy_pass http://127.0.0.1:8088;: Passes requests to your Superset instance running locally.

5. Test Nginx Configuration:

Before applying the changes, test your Nginx configuration:

Bash

sudo nginx -t

If the test is successful, you should see a message indicating that the configuration is okay.

6. Reload Nginx:

Reload Nginx to apply the new configuration:

Bash

sudo systemctl reload nginx

7. Access Apache Superset via Nginx:

Now, you can access Apache Superset via Nginx using the server name or IP address you configured in the Nginx reverse proxy.

For example, if you set up Nginx with the server name superset.example.com, you can access Superset by visiting:

Bash

http://superset.example.com/

Nginx will proxy requests to the Apache Superset server.

By following these steps, you have set up Nginx as a reverse proxy for Apache Superset, allowing you to control access and potentially enhance security or performance.
