Longest Common Subsequence (LCS) Algorithm: Dynamic Programming Approach

The Longest Common Subsequence (LCS) problem is a classic computer science problem that finds applications in diverse fields from bioinformatics (DNA sequence alignment) to version control systems (diff algorithms).

Problem Statement:
Given two sequences X and Y, find the length of the longest subsequence present in both of them. A subsequence is a sequence that appears in the same relative order but not necessarily contiguous.

Example:

• X: “ABCBDAB”
• Y: “BDCABA”
• LCS: “BCBA” (length 4)

Key Concepts

1. Optimal Substructure

The LCS problem has an optimal substructure property, meaning the optimal solution can be constructed from optimal solutions to its subproblems.

2. Overlapping Subproblems

When solved recursively, the problem contains many overlapping subproblems that are solved repeatedly, making it ideal for dynamic programming.

Recursive Formulation

Let X[0..m-1] and Y[0..n-1] be two sequences of lengths m and n respectively.

The recursive solution considers two cases:

1. Last characters match: LCS(X[0..m-1], Y[0..n-1]) = 1 + LCS(X[0..m-2], Y[0..n-2])
2. Last characters don’t match: LCS(X[0..m-1], Y[0..n-1]) = max(LCS(X[0..m-2], Y[0..n-1]), LCS(X[0..m-1], Y[0..n-2]))

Dynamic Programming Approach

1. Tabulation (Bottom-Up)

We construct a 2D array dp[m+1][n+1] where:

• dp[i][j] = length of LCS of X[0..i-1] and Y[0..j-1]
• dp[0][j] = 0 and dp[i][0] = 0 (base cases)
• Fill the table using the recursive relations

2. Time and Space Complexity

• Time Complexity: O(mn)
• Space Complexity: O(mn) (can be optimized to O(min(m,n)))

C Implementation

#include <stdio.h>
#include <string.h>

<em>// Utility function to find maximum of two integers</em>
int max(int a, int b) {
    return (a > b) ? a : b;
}

<em>// Returns length of LCS for X[0..m-1], Y[0..n-1]</em>
int lcs_length(char *X, char *Y, int m, int n) {
    int dp[m+1][n+1];
    int i, j;

    <em>// Build dp table in bottom-up fashion</em>
    for (i = 0; i <= m; i++) {
        for (j = 0; j <= n; j++) {
            if (i == 0 || j == 0)
                dp[i][j] = 0;
            else if (X[i-1] == Y[j-1])
                dp[i][j] = dp[i-1][j-1] + 1;
            else
                dp[i][j] = max(dp[i-1][j], dp[i][j-1]);
        }
    }
    return dp[m][n];
}

<em>// Function to print the LCS</em>
void print_lcs(char *X, char *Y, int m, int n) {
    int dp[m+1][n+1];
    int i, j;

    <em>// Build dp table</em>
    for (i = 0; i <= m; i++) {
        for (j = 0; j <= n; j++) {
            if (i == 0 || j == 0)
                dp[i][j] = 0;
            else if (X[i-1] == Y[j-1])
                dp[i][j] = dp[i-1][j-1] + 1;
            else
                dp[i][j] = max(dp[i-1][j], dp[i][j-1]);
        }
    }

    <em>// Following code is used to print LCS</em>
    int index = dp[m][n];
    char lcs[index+1];
    lcs[index] = '\0'; <em>// Terminate the string</em>

    i = m, j = n;
    while (i > 0 && j > 0) {
        <em>// If current characters match, they are part of LCS</em>
        if (X[i-1] == Y[j-1]) {
            lcs[index-1] = X[i-1];
            i--; j--; index--;
        }
        <em>// If not, find the larger of two and go in that direction</em>
        else if (dp[i-1][j] > dp[i][j-1])
            i--;
        else
            j--;
    }

    printf("LCS: %s\n", lcs);
}

int main() {
    char X[] = "ABCBDAB";
    char Y[] = "BDCABA";
    int m = strlen(X);
    int n = strlen(Y);

    printf("Length of LCS is %d\n", lcs_length(X, Y, m, n));
    print_lcs(X, Y, m, n);

    return 0;
}

Explanation of the Code

1. lcs_length function:
   • Creates a DP table of size (m+1)×(n+1)
   • Fills the table using bottom-up approach
   • Returns the value in dp[m][n] which is the LCS length
2. print_lcs function:
   • First builds the DP table same as lcs_length
   • Then traces back from dp[m][n] to construct the actual LCS string
   • Uses the DP table to determine the path of matched characters
3. main function:
   • Defines two input strings
   • Calls lcs_length to get the length of LCS
   • Calls print_lcs to print the actual subsequence

Space Optimization

The space complexity can be reduced from O(mn) to O(min(m,n)) by using two 1D arrays instead of a 2D array:

int lcs_optimized(char *X, char *Y, int m, int n) {
    int dp[2][n+1];
    int i, j;

    for (i = 0; i <= m; i++) {
        for (j = 0; j <= n; j++) {
            if (i == 0 || j == 0)
                dp[i%2][j] = 0;
            else if (X[i-1] == Y[j-1])
                dp[i%2][j] = dp[(i-1)%2][j-1] + 1;
            else
                dp[i%2][j] = max(dp[(i-1)%2][j], dp[i%2][j-1]);
        }
    }
    return dp[m%2][n];
}

Applications of LCS

1. Version Control Systems: Used in diff tools to compare files
2. Bioinformatics: DNA sequence alignment
3. Plagiarism Detection: Comparing documents
4. Data Comparison: Database synchronization
5. Speech Recognition: Matching spoken words with text

Variations of LCS Problem

1. Longest Common Substring: Contiguous characters
2. Shortest Common Supersequence
3. Edit Distance: Minimum operations to convert one string to another
4. Multiple Sequence Alignment: LCS for more than two strings

Performance Analysis

For two strings of lengths m and n:

• Time Complexity: O(mn) – We fill a table of size m×n
• Space Complexity:
  • Basic version: O(mn)
  • Optimized version: O(min(m,n))

This implementation provides a complete solution to the LCS problem, demonstrating both the length calculation and the actual subsequence reconstruction. The space-optimized version shows how to reduce memory usage while maintaining the same time complexity.
