netsniff-ng is a high-performance Linux networking toolkit designed for packet sniffing, network analysis, and traffic generation. It is part of Kali Linux’s suite of penetration testing and network security tools. Unlike traditional sniffers like Wireshark or tcpdump, netsniff-ng is optimized for zero-copy packet processing, making it extremely fast and efficient.

What is netsniff-ng?

netsniff-ng is a suite of networking tools that includes:

• Packet capture (netsniff-ng)
• Traffic generation (trafgen)
• Flow-based analysis (flowtop)
• Packet filtering (bpfc)
• PCAP file manipulation (mausezahn)

It is designed for high-speed packet processing (e.g., gigabit networks) and supports BPF (Berkeley Packet Filter) for advanced filtering.

How Does netsniff-ng Work?

• Uses zero-copy techniques to minimize CPU overhead.
• Supports multiple input/output formats (PCAP, PcapNG, etc.).
• Can replay, modify, and generate network traffic.
• Works at kernel level for maximum efficiency.

Installation in Kali Linux

Since Kali Linux includes netsniff-ng by default, you can verify its presence with:

netsniff-ng --version

If missing, install it via:

sudo apt update && sudo apt install netsniff-ng

Basic Usage Examples

1. Capture Packets to a File

sudo netsniff-ng -i eth0 -o capture.pcap

• -i eth0: Interface to capture from.
• -o capture.pcap: Save packets to a PCAP file.

2. Live Packet Analysis

sudo netsniff-ng -i eth0 --in --silent --verbose

• --in: Read from network interface.
• --silent: Suppress stats.
• --verbose: Show packet details.

3. Read from a PCAP File

netsniff-ng -i capture.pcap --in

Advanced Usage Examples

1. Filter Traffic with BPF

sudo netsniff-ng -i eth0 -o http-only.pcap "tcp port 80"

• Captures only HTTP traffic.

2. Replay Packets

sudo netsniff-ng -i capture.pcap --out eth0 --rate=1000

• Replays packets at 1000 packets per second.

3. Generate Traffic with trafgen

sudo trafgen -i traffic.cfg -o eth0 --cpp -n 1000

• Uses a config file (traffic.cfg) to craft custom packets.
• --cpp: Preprocess with C preprocessor.
• -n 1000: Send 1000 packets.

Command-Line Options

I/O Configuration

Performance Tuning

Filtering

Miscellaneous

Practical Examples

1. Basic Packet Capture

sudo netsniff-ng -i eth0 -o capture.pcap -s -b 0

• Captures from eth0 to capture.pcap
• Silent mode (-s), bound to CPU 0 (-b 0)

2. Advanced Traffic Filtering

sudo netsniff-ng -i eth0 -f "tcp port 80" -l -V

• Filters HTTP traffic
• Shows ASCII output (-l) with verbose metadata (-V)

3. PCAP Replay with Rate Limiting

sudo netsniff-ng -i attack.pcap -o eth0 -k 1000 -s -b 1

• Replays at 1000 packets/sec (-k)
• Silent mode, bound to CPU 1

4. Distributed Capture (Fanout Groups)

# Terminal 1 (CPU 0):
sudo netsniff-ng -i eth0 -o /tmp/cap1 -C 123 -K cpu -b 0

# Terminal 2 (CPU 1):
sudo netsniff-ng -i eth0 -o /tmp/cap2 -C 123 -K cpu -b 1

• Distributes capture load across CPUs using fanout group 123

5. Wireless Monitoring

sudo netsniff-ng -i wlan0 -R -o wlan_capture.pcap

• -R captures raw 802.11 frames

Advanced Use Cases

Bypassing Network Filters

sudo netsniff-ng -i eth0 -t outgoing -o /dev/null -f "not src host 192.168.1.100"

• Captures only outbound traffic excluding a specific host

Creating trafgen Configs

sudo netsniff-ng -i sample.pcap -o attack.cfg -s

• Converts PCAP to trafgen-compatible config

Stealth Monitoring

sudo netsniff-ng -i eth0 -o /tmp/cap -F 100MiB -u nobody -g nogroup -s

• Dumps every 100MB to new file
• Runs as unprivileged user

Performance Optimization Guide

1. CPU Binding: Always use -b for NUMA optimization
2. Ring Buffers: Increase with -S for high-speed networks
3. Fanout Groups: Use -C/-K for multi-core scaling
4. Memory Mapped I/O: -m for faster PCAP replay
5. Priority: -H for reduced packet drops

Pro Tips

1. Combining with trafgen:

netsniff-ng -i capture.pcap -o attack.cfg && sudo trafgen -i attack.cfg -o eth0

2. Long-term Monitoring:

sudo netsniff-ng -i eth0 -o /var/log/pcaps/ -F 1hr -P "network_cap"

3. Debugging Complex Filters:

netsniff-ng -i eth0 -f "vlan and tcp" -B

Real-World Use Cases

1. Network Troubleshooting

• Capture and analyze traffic to diagnose connectivity issues.
• Example: sudo netsniff-ng -i eth0 -o debug.pcap

2. Security Analysis

• Detect malicious traffic (e.g., port scans, DDoS).
• Example: sudo netsniff-ng -i eth0 "tcp port 22"

3. Traffic Replay for Testing

• Simulate attacks (e.g., replaying captured attacks in a lab).
• Example: sudo netsniff-ng -i attack.pcap --out eth0

4. Custom Packet Crafting

• Generate test traffic (e.g., TCP SYN floods for stress testing).
• Example: sudo trafgen -i syn-flood.cfg -o eth0

Troubleshooting Tips

1. Permission Errors

• Run with sudo (requires root privileges).
• Ensure the interface is up: sudo ifconfig eth0 up

2. No Packets Captured

• Check interface name: ip link show
• Verify promiscuous mode: sudo ifconfig eth0 promisc

3. BPF Filter Not Working

• Test filters with tcpdump first:

sudo tcpdump -i eth0 "tcp port 80"

• Ensure correct syntax.

4. High CPU Usage

• Use --silent to reduce overhead.
• Limit capture rate: sudo netsniff-ng -i eth0 --rate=1000

netsniff-ng Toolkit: Packages & Binaries Breakdown

The netsniff-ng suite consists of multiple specialized networking tools, each serving a unique purpose in packet analysis, traffic generation, and network diagnostics. Below is a detailed breakdown of each component, including installation, usage, and practical examples.

netsniff-ng (Packet Sniffer & Analyzer)

Purpose: High-performance packet capture and analysis.
Key Features:

• Zero-copy packet processing for maximum efficiency.
• Supports BPF filtering.
• Can read/write PCAP files.

Installation (Kali Linux)

sudo apt update && sudo apt install netsniff-ng

Basic Usage

sudo netsniff-ng -i eth0 -o capture.pcap  # Capture packets to file
sudo netsniff-ng -i capture.pcap --in    # Read from PCAP file

Advanced Usage

# Capture only HTTP traffic
sudo netsniff-ng -i eth0 -o http.pcap "tcp port 80"

# Replay packets at 1000 pps
sudo netsniff-ng -i attack.pcap --out eth0 --rate=1000

trafgen (Traffic Generator)

Purpose: Craft and inject custom packets at high speed.
Key Features:

• Supports custom packet templates.
• Useful for stress testing and DoS simulations.

Basic Usage

# Generate random traffic on eth0
sudo trafgen -i /dev/urandom -o eth0 -n 1000

# Craft packets from a config file
sudo trafgen -i custom.cfg -o eth0 --cpp

Example Config (custom.cfg)

/* SYN Flood Example */
{
  /* Ethernet Header */
  0x00, 0x11, 0x22, 0x33, 0x44, 0x55,  /* Source MAC */
  0x00, 0x11, 0x22, 0x33, 0x44, 0x56,  /* Dest MAC */
  0x08, 0x00,                          /* EtherType (IPv4) */

  /* IPv4 Header */
  0x45, 0x00, 0x00, 0x3c,              /* Version, IHL, TOS, Total Length */
  0x00, 0x01, 0x00, 0x00,              /* ID, Flags, Fragment Offset */
  0x40, 0x06, 0x00, 0x00,              /* TTL, Protocol (TCP), Checksum */
  0xc0, 0xa8, 0x01, 0x01,              /* Source IP (192.168.1.1) */
  0xc0, 0xa8, 0x01, 0x02,              /* Dest IP (192.168.1.2) */

  /* TCP Header */
  0xde, 0xad, 0xbe, 0xef,              /* Source Port (57005) */
  0x00, 0x50, 0x00, 0x00,              /* Dest Port (80), Seq Num */
  0x00, 0x00, 0x00, 0x00,              /* Ack Num */
  0x50, 0x02, 0x00, 0x00,              /* Header Length, SYN Flag */
  0x00, 0x00, 0x00, 0x00,              /* Window Size, Checksum, Urgent */
}

mausezahn (Packet Crafting & Traffic Generation)

Purpose: Advanced packet crafting with a Cisco-like CLI.
Key Features:

• Supports ARP, TCP, UDP, ICMP, and more.
• Can simulate complex network scenarios.

Basic Usage

# Send a single ICMP ping
sudo mausezahn eth0 -c 1 -t icmp

# Flood UDP packets
sudo mausezahn eth0 -B 192.168.1.1 -t udp dp=80,p=1 -c 1000

Advanced Usage

# Craft a custom TCP SYN packet
sudo mausezahn eth0 -a rand -b rand -A 192.168.1.1 -B 192.168.1.2 -t tcp "dp=80, flags=syn" -P "Hello World"

flowtop (Flow-Based Traffic Monitor)

Purpose: Real-time flow statistics (like iftop but with more details).
Key Features:

• Displays active network flows.
• Supports sorting by bandwidth, packets, etc.

Basic Usage

sudo flowtop -i eth0

Keybindings

• s → Sort by bandwidth.
• n → Switch between numeric and hostname display.

ifpps (Interface Statistics)

Purpose: Displays real-time network stats (similar to ip -s but more detailed).
Key Features:

• Shows packets, errors, drops, and bandwidth.

Basic Usage

sudo ifpps eth0

Output Example

eth0  [RX: 1.2 MB/s] [TX: 0.8 MB/s] [TOTAL: 2.0 MB/s]

bpfc (BPF Compiler)

Purpose: Compiles BPF filters for use with netsniff-ng/tcpdump.
Key Features:

• Converts human-readable filters to BPF bytecode.

Basic Usage

echo "tcp port 80" | bpfc > http.bpf
sudo netsniff-ng -i eth0 -f http.bpf

astraceroute (AS Path Traceroute)

Purpose: Traceroute with AS (Autonomous System) information.
Key Features:

• Shows the AS path of each hop.
• Useful for network mapping.

Basic Usage

sudo astraceroute google.com

Output Example

1  AS1234  192.168.1.1 (Router1)
2  AS5678  10.0.0.1 (ISP-Gateway)
3  AS9101  216.239.32.1 (Google)

curvetun (Secure VPN Tunnel)

Purpose: Lightweight VPN using Curve25519 encryption.
Key Features:

• Encrypts traffic with modern crypto (NaCl/Curve25519).
• Works over UDP.

Basic Setup

# Server
sudo curvetun -i eth0 -k server.key -p 5000 -d

# Client
sudo curvetun -i eth0 -k client.key -p 5000 -c server-ip -d
